Switch, level, variable insertion depth, vertical float, extension

Variable Insertion Depth Vertical Float Switch

N/O version has contacts which are open when the tank is empty, N/C version has contacts which are closed when the tank is empty
Overall depth can be varied between 150mm and 450mm by adjusting its position in a sliding clamp
Up to 3 extension units (306mm long) may be added to provide insertion depths up to 1350mm (see accessories)
Temperature range, 0 to 75°C
Switching depth, 123-423mm
Electrical life, 5 x 10⁶ operations
Polypropylene Float, PPS stem and PVC class 7 tube material

Approvals

UL , WRAS
